Fully Automatic Rotary Die Cutting Machine

YMQA-320 Fully Automatic Rotary Die Cutting Machine is with function of auto length counting, number counting, length setting, auto stop. The cutting speed is up to 200m/min.

Get a free quote DownLoad

Product Details

Die cutting axle head fixing seat adopt circle design, it is easy for assemble and disassemble, compare with traditional square shape fixing seat, it save half time. Die cutting pressure adjusting screw arbor is rotation structure, it do not need to take off. Up rewind adopt turret structure to improve work efficiency. Transmission adopt synchronous belt to reduce noise. It is with unwind, rewind and waste collection all adopt magnetic powder brake/clutch to control, operation stable. Unwind adopt auto tension control for constant tension, rewind adopt taper tension control. Unwind, rewind, waste collection air shaft all auto air charge. The rotary die cutting machine is with function of auto length counting, number counting, length setting, auto stop, ultrasonic sensor web guiding etc.

Technical Parameters

Slitting speed	200m/min
Die cutting speed	150m/min
Die cutting girth	200-500mm
Max.width of roll	320mm
Max.diameter of unwinding roll	600mm
Max.diameter of Rewinding roll	Up: 300mm(turret) Down: 600mm
Overall size	19009001435mm
Weight	1000KG
Power supply	AC380V, 3 phase

Products Show

Rotary die cutting station

Slitting unit with rotary knife standard, and razor knife can be installed as optional

Up turret rewinder and down single rewinder, up turret rewinder can be put with 1” and 1.5” air shaft for small roll rewind, web path from right to left for convenient operation.
