ZD-320 Paper Folding Machine
ZD-320 Paper Folding Machine uses a touch screen to operate, with dual servo motors and PLC. The machine can rise, fall or move forward, and can set the number of automatic stops.
ZD-320 Paper Folding Machine uses a touch screen to operate, with dual servo motors and PLC. The machine can rise, fall or move forward, and can set the number of automatic stops.
.png)
The Paper Folding Machine with touch screen for operation, (folding length can be set on the touch screen), with double servo motor and PLC. Machine and rise up and down or move forward, it can do zigzag ling slitting, waste rewind, can set qty for auto stop. Machine unwind adopt half auto constant tension, is suitable for logistic label, boarding pass, scenic ticket, game coin etc product folding. This machine can be equipped with printing machine, flat bed die cutting machine, rotary die cutting machine.
|
Max web width |
320mm |
|
Max putting diameter |
800mm |
|
Max. Folding length |
310mm |
|
Min. Folding length |
80mm |
|
Min. Folding width |
70mm |
|
Voltage |
220V, 60hz, single phase |
|
Power |
3.5kw |
|
Max. Folding speed |
80m/min |
|
Overrll dimensions(L*W*H) |
1350*1000*1280mm |
|
Machine Weight |
600KG |
