Model: QFJ-E1600

Jumbo Roll slitter rewinder machine

QFJ-E1600 Jumbo Roll Slitter Rewinder cuts wide rolls of material into narrow strips at high speed. Speed is up to 400/min and with 4 sets of servo motor.

Product Details

Large roll slitting and rewinding machine with fully automatic tension controller and magnetic powder brake unwind, maximum running speed 400m/min, rewinding with chain, easy to move the rewinding roll, can handle non-woven fabrics, textiles, printing paper, wrapping paper, labelling paper and so on.

Technical Parameters

No.	Description	Parameter	Unit	Note
1.	Suitable material	Adhesive label/paper/CPP/PET/PE/soft alu laminated film/alu chromed film etc. Roll material
2.	Web thickness range	0.05--0.2	mm
3.	Valid width	1600	mm
4.	Roll surface length	1650	mm
5.	Unwind diameter	① 1000 (MAX)	mm
6.	Rewind diameter	① 1000 (MAX)	mm
7.	Mechnical speed max.	400	m/min
8.	Tension range	10—400	N
9.	Web guide precision/slitting precision	±0.3/±0.2	mm
10.	Web guide stroke	± 70	mm
11.	Slitting width	300-1600	mm
12.	Length count precision	±1/1000	m
13.	Voltage	AC 380±5%,50HZ	V	3 phase
14.	Air supply	0.6	Mpa
15.	Weight	About 6000	Kg
