Model: QFJ-C

Surface Winding Slitting Machine

QFJ-C Surface Winding Slitting Machine adopts central surface contact winding, Suitable for PVC/BOPP/CPP/PET/composite film/aluminum foil/paper and other rolls.

Product Details

This Surface Winding Slitting Machine adopts central surface contact winding, and each winding shaft is controlled by a separate servo motor. Suitable for PVC/BOPP/CPP/PET/composite film/aluminum foil/paper and other rolls.This innovative design greatly improves the precision and stability of winding and slitting. During the rewinding process, each rewinding shaft is precisely controlled by an independent servo motor. This configuration not only realizes the flexible adjustment of multi-axis synchronization, but also ensures the precise coordination between the rewinding shafts.

Technical Parameters

Slitting speed 400/min

Independent shaft free feeding

Min.Slitting width 3mm

4sets servo motor controll

Unwinding diameter 1200mm（Customizable）

Rewinding diameter 600mm（Customizable）

Machine model	800	1300	1800
Slitting speed	400/min	400/min	400/min
Unwinding width	600mm	1300mm	1800mm
Min slitting width	3MM	5MM	10MM
Unwinding diameter	Φ1200mm	Φ1200mm	Φ1200mm
Rewinding diameter	Φ600mm	Φ600mm	Φ600mm
Main servo motor power	4KW	5.5KW	5.5KW
Revinding servo motor power	2*3KW	2*4KW	2*4KW
Unwinding servo motor power	4KW	5.5KW	7.5KW
