Model: RY-320-5

Five Color Label Flexo Printing Machine

The Five Color Label Flexo Printing Machine adopts imported converter to govern in a steepless way. Feeding and discharging are controlled through magnetic powder brake and clutch. Adopt ceramic mesh distributor roller, which is characterized by durability , wear resistance, and corrosion resistance.

Product Details

The doctors can be Used, which is more efficient for reducing the times for changing in order to increase the production efficiency. The printing unit can register in 360degrees. Each printing unit can indepen deftly gear and loosen to have the units continue printing. The printing units are all equipped with a group of infrared dryers respectively. The roofing device is adopted with a group of infrared dryers respectively. The inking roller can automatically fall off at stoppage and transfer at low speed in order to keep the ink from being bry and solid. The roll feeding, printing, auto infrared drying. Laminating and rolling can be processed in one processing.

Technical Parameters

Model	RY-320-5
Machine color	5 color
Max.material width	320mm
Max. Printing width	310mm
Printing material	Paper: 30-350 gsm
Printing length	175-355mm
Mechanical speed	70m/min
Printing speed	30-60 m/min
Register precision	±0.1mm
Unwinder diameter	600mm
Rewinder diameter	500mm
Anilox roll	Ceramic anilox roll 5 pcs
Inking running way	Reverse angle doctor blade 5 pcs
EPC system	Web guiding
Tension system	Automatic tension controller for unwinding and rewinding
Unwind system	Auto cylinder unwind
Printing pressure	Mechanical adjust
Drying way	Electrical heat drying, 5 IR dryer,
Powder brake	7.5kg, for unwind
